Camera

• 4K dual-lens technology delivers a wide 113° field of view (FOV) with 18X zoom
• 4K 3X varifocal lens: FOV (D/H/V) 92°/81°/50°
• 4K fixed lens: FOV (D/H/V) 113°/105°/71°
• Sony 4K sensor: ultra-crystal-clear image in any lighting
• Frame rate: (16:9) 1280 x 720 at 60, 30, 15fps; 4K, 3264 x 1836, 2560 x 1440, 1920 x 1080, 1600 x 900, 960 x 540, 848 x 480, 800 x 448, 640 x 360 at 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 30, 15fps
• Adjustable audio fence: Freedom to define wide/ medium/ narrow view fence
• SmartFrame & SmartSpeaker: Automatic tracking and FOV adjustment to fit all participants and focus on the speaker
• Presentation mode: Voice-triggered tracking on both defined areas and speakers
• Smart gallery* function enhances visibility
• Gesture control for intuitive camera control
• WDR, white balance and more image settings via Room Management (PTZApp 2)
• Minimum focus distance: 100 cm
• People counting API: Enterprises and third-party software providers can obtain people-counting and meeting-interval data tor better understand meeting space usage

Motorized Pan and Tilt Movement

• Pan: Total horizontal viewing area 165°
• Tilt: Total vertical viewing area 101°
• 10 camera presets

Audio

• 14-element beamforming microphone array
• 10 meters pickup range*
• Volume up to 96 dB SPL at 1/2 m
• Echo cancellation
• AI noise suppression

HDMI

• One cable solution: Built-in USB 3.1 (Gen 1) to HDMI adapter
• 4K HDMI output to TV*

Connectivity

• 12V/5A power adapter
• Mini DIN 6 for RS-232 connection
• USB 3.1 type B port, backward compatible with USB 2.0
• HDMI out connection (USB to HDMI adapter)
• Phone-in (1Vrms input)/speaker-out for HA system*
• RJ45 ports x2: one for Ethernet, one for audio expansion speakerphone / microphone
• USB 2.0 type A x3: Wireless connection**, USB to support IFP USB touch back, and expansion port

Video Format

• YUV, YUY2, M-JPEG
• Network video compression formats: H.264
• Network protocols: RTSP, RTMP

USB

• 3.1 Gen 1, backward compatible with USB 2.0
• UVC 1.1 (USB Video), UAC 1.0 (USB Audio)

Control

• IR remote control
• WebUI: IP access via Chrome browser (Chrome 76.x or later; Internet Explorer not supported)
• VISCA/pelco P/pelco D via RS-232/VISCA over IP
• UVC/UAC plug-and-play
• Room Management (PTZApp 2)

Mount and Security

• Wall-mount bracket (included)
• TV VESA mount kit (optional)
• Kensington security lock

System Requirements

Software

• Windows® 7/10/11
• Mac OS X 10.14 or later
• Chromebox 3 version 94.0.4606.114 or later

Hardware

• 3.2 GHz Intel® Core™ i5-4460 processor
• 4 GB RAM or more
• USB 3.1 port, backward compatible with USB 2.0

Power Supply

• AC 100V–240V, 50/60 Hz
• Consumption: 12V/4.5A

Software Tools

• Room Management (PTZApp 2) : Supports Windows® 7 or later, macOS® 11.6 or later
• Enterprise Management (PTZ Management) : Supports Windows® 10 or later
• EZManager 2 : Supports Windows® 7 or later
• EZLive : Supports Windows® 7 or later, macOS® 10.13 or later

Environmental Data

• Operation temperature: 0°C ~ 40°C
• Operation humidity: 20% ~ 80%
• Storage temperature: -20°C ~ 60°C
• Storage humidity: 20% ~ 80%

Dimensions

• Package dimensions: 872 mm (L) x 197 mm (W) x 260 mm (H)
• Package weight: 7.4 kg
• Camera: 791 mm (L) x 128 mm (W) x 126 mm (H)/3.3 kg
• Remote control: 150 mm (L) x 42 mm (W) x 19 mm (H)/50 g

Compatible Applications

• Zoom, Microsoft® Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel® Unite™, Fuze, Adobe® Connect™, CyberLink U Meeting®, Cisco WebEx® GoToMeeting™, LiveOn, Microsoft® Lync™, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit
