Display

• Diagonal Size 13"
• Panel Type ADS
• Resolution 1,920 x 1,080
• Pixel Pitch (HxV) 0.153 (H) x 0.153 (V)
• Brightness (Typ) 500(w/o glass)
• Contrast Ratio 600:1
• Viewing Angle (H/V) 178/178
• Response Time 30ms
• Color Gamut 45%
• Glass Haze 25%, 10%(Glass)
• H-Scanning Frequency 30~81kHz
• Maximum Pixel Frequency 594MHz
• V-Scanning Frequency 48~75Hz
• Contrast Ratio (Dynamic) 10000:1
• Operation Time Support 16/7

Connectivity

• No HDMI In 1
• DP In No
• Version of HDMI 1.4
• Version of DP No
• Version of HDCP 2.2
• USB 1
• IR In No
• Audio In No
• Audio Out Stereo Mini Jack
• RS232 In Yes
• RJ45 In Yes
• WiFi Yes
• 3G Dongle

Power

• Power Supply AC100-240V 50/60Hz
• Power Consumption (On Mode) 27.5W
• Power Consumption (Sleep Mode) 0.5W

Dimension

• Set Dimension (WxHxD) 322 x 193.5 x 29.8 mm
• Package Dimension (WxHxD) 376 x 132 x 248 mm

Mechanical Specification

• VESA Mount 100 x 100 mm
• Bezel Width 13.1
• Bezel Color Charcoal Black
• Frame Material Non-Glossy

Optional Feature

• Touch Yes
• Mount No
• Stand Inbox(Simple Stand) (2ea)

SoC

•  OS Version Tizen 4.0
• Flash Memory Size 8GB

Certification and Compliance

• EMC Class B
• Safety 60950-1, 62368-160950-1, 62368-1
